P2.6 Indoor LED Panels 192x192 Resolution LED Rental Screen 7680Hz

Brand Name: TuringLED
Model Number: FBslim2.6
MOQ: 10 PCS
Packaging Details: Flight case
Payment Terms: 100% TT
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE,RoHS,FCC
Document:
FBslim2.6 Panel.pdf
Name:
Indoor LED Panels
IN/OUT:
Indoor
Target Market:
Event Rental
Maintenance:
All Parts Front Access(0 Back Space) + Back Access
User-Friendly Design:
Single-person Installation, Tool-free Central Control Box Replacement,Tool-free Module Replacement
Visual Features:
7680Hz,Supports Calibration Dot By Dot Flash Built-in Module
Curve Locks:
Yes
90°:
Support
Highlight:

P2.6 Indoor LED Panels

,

Indoor LED Panels 192x192

,

LED Rental Screen 7680Hz

Product Description
FBslim2.6 Indoor Rental LED Screen with 2.6mm Pixel Pitch Die Casting Aluminum and 192 x 192 Panel Resolution
Product Overview

FBslim can lock into standard Aluminum profile

It is All-in-one indoor LED display panel designed for versatile applications including exhibitions, events, wall mounting, double-sided displays, 90-degree corner installations, and shopping mall banners.

FBslim is 100% front access and also 100% back access including modules, card, power supply and cables.

P2.6 Indoor LED Panels 192x192 Resolution LED Rental Screen 7680Hz 0

Technical Specifications
Parameter Specification
Pixel Pitch 2.601 mm
Panel Resolution 192 * 192 Dots
Brightness 600-1800 Nits (after calibration)
Pixel Configuration SMD1515, SMD2IN1
Scanning Mode 1/24 or 1/16
Weight per Panel 5.7 kg (GOB: 6.06 kg per panel)
Pixels per Square Meter 147,456
Refresh Rate 7,680 Hz
Input Power (Max/Avg) 180W / 60W per Panel
Panel Dimensions 500 * 500 * 40 mm
Panel Area 0.25 m²
Panel Material Die Casting Aluminum
Ingress Protection IP30 Front / IP30 Rear
Certifications CE, EMC Class A, RoHS, FCC
Packaging Flight Case
Key Features
  • Support 5G and HDR10
  • Calibration data built-in IM technology
  • Lock into Alu Profile 4040
  • All front access
  • All back access
  • Versatile all-in-one indoor display solution
  • High pixel density for superior image quality
  • Robust die-cast aluminum construction
  • Multiple mounting and installation options
  • Professional certifications for quality assurance

P2.6 Indoor LED Panels 192x192 Resolution LED Rental Screen 7680Hz 1
